Function & Design: CAFC Reverses Utility Patent Infringement and Remands Design Patent Dispute
Words matter
The U.S. Court of Appeals for the Federal Circuit, in a precedential opinion authored by Judge Dyk and joined by Judges Linn and Stark, recently issued a decision in Smartrend Manufacturing Group (SMG), Inc. v. Opti-Luxx Inc., providing critical clarifications on two distinct but related areas of patent law: the limits of the doctrine of equivalents for a utility patent and the precise interpretation of descriptive language in a design patent.
In a move that underscores the power of the patent specification, the court reversed a jury’s finding of utility patent infringement, holding that no reasonable jury could find an “equivalent” product that fundamentally lacks the key functions described in the patent (Slip Op., p. 18). Simultaneously, the court vacated the infringement finding on a related design patent, ruling that the district court applied an erroneous claim construction (p. 10). This decision serves as a potent reminder for patent practitioners and owners about the exacting standards of claim construction and the boundaries of infringement analysis.
Background of the Dispute
The conflict centers on illuminated signs, specifically those used on school buses (p. 2). Smartrend Manufacturing Group (SMG) accused Opti-Luxx of infringing two of its patents: U.S. Patent No. 11,348,491 (the ‘491 utility patent) and U.S. Design Patent No. D932,930 (the D’930 design patent).
The ‘491 utility patent claims a sign constructed with several specific components, including a “frame surrounding a perimeter of the translucent panel... for mounting the sign to the school bus” (p. 5). The patent’s specification went to great lengths to describe the benefits of this frame being a separate component (pp. 12-13, 16).
The D’930 design patent claims the “ornamental design for an LED light panel, as shown and described” (p. 3). The drawings in the patent used oblique shading lines, and the patent’s written description included a key statement: “oblique shading lines visible in the front and perspective views denote transparency” (p. 3).
Opti-Luxx’s accused product is a single-piece illuminated sign. Its rigid plastic housing, which forms the product’s perimeter, is “not separable from the rest of the sign” (p. 2). The sign features a translucent yellow lens and opaque black lettering.
A jury in the U.S. District Court for the Western District of Michigan found that Opti-Luxx infringed both patents. Based on this verdict, the district court denied Opti-Luxx’s motion for judgment as a matter of law (JMOL) and issued a permanent injunction (p. 2). Opti-Luxx appealed to the Federal Circuit, challenging the district court’s claim constructions and the sufficiency of the evidence for the jury’s verdict.
The Federal Circuit’s opinion effectively bifurcated the case, addressing each patent and its distinct legal errors separately.
The ‘491 Utility Patent: A Failed Equivalence Argument
The central issue for the ‘491 patent was the “frame.” The district court had construed the term “frame” to mean “’a separate, distinct component’” (p. 12), relying on the patent’s specification. The Federal Circuit affirmed this construction as correct, noting that the specification “repeatedly, consistently, and exclusively... refers to a ‘separate’ mounting frame” (pp. 12-13).
Because Opti-Luxx’s integrated, non-separable frame did not meet this “separate” limitation, there was no literal infringement. The case at trial hinged entirely on the doctrine of equivalents.
Smartrend argued that the accused product’s integrated housing was equivalent to the claimed “frame” because it performed substantially the same function (surrounding the panel and mounting the sign), in substantially the same way, to achieve the same result (p. 14). The jury agreed.
The Federal Circuit, however, found this conclusion legally unsupportable. The court explained that the function of a claim element is defined not just by the claim language but also by the patent’s specification. The ‘491 patent’s specification did not merely describe a frame; it “’extols the virtues of its separate mounting frame’” (p. 16). These virtues included critical functions that Opti-Luxx’s product could not perform. For example, the specification described how the frame is “’configured to removably receive the sign’” (p. 13) so that “service or replacement of the sign can be performed without having to remove the entire installation” (p. 16).
Smartrend’s own expert conceded at trial that the accused product was “’not capable of doing that’” (p. 18). This admission was fatal. The Federal Circuit held that JMOL should have been granted to Opti-Luxx.
“The undisputed evidence shows that the accused device does not perform the required functions. The patent indicates that the claimed invention can ‘removably receive the sign’ so that the signs can be exchanged, customized, or serviced without removing the entire installation... Smartrend’s expert witness, Mr. York, conceded that the accused product is ‘not capable of doing that.’... Therefore, no reasonable jury could have found that the accused product infringed the ‘491 patent.” (p. 18)
This holding serves as a firm rejection of an overly broad application of the doctrine of equivalents. It confirms that an accused product cannot be “equivalent” if it is incapable of performing the specific functions that the patent specification identifies as key advantages of the claimed invention.
The D’930 Design Patent: “Transparency” Does Not Mean “Translucency”
The dispute over the D’930 design patent turned on a single word in its description: “transparency.” The district court, in its claim construction, had determined that “transparency” was “capable of being synonymous with translucency” (p. 10) and instructed the jury that “’
$$t$$
he Court has found the word transparency to mean both transparent and translucent’” (p. 4).
The Federal Circuit flatly rejected this construction as erroneous.
The court explained that in a design patent claimed “as shown and described,” the scope is limited by both the drawings and the description (p. 9). While patent drawings might use shading lines that could denote transparency, translucency, or reflective surfaces, the D’930 patent’s description explicitly narrowed this meaning by stating the lines “denote transparency” (p. 10).
The court ruled, “The district court’s construction was erroneous... Transparency is not synonymous with translucency and does not mean both transparent and translucent” (p. 10). This incorrect instruction tainted the jury’s verdict, requiring the judgment to be vacated and the case remanded for a new trial.
The Federal Circuit also issued a caution for the new trial, instructing that any expert testimony must be properly grounded. It warned that “’conclusory’ testimony by experts unsupported by reliable extrinsic material—such as special-purpose dictionaries or other objective evidence—is insufficient” to establish an art-specific meaning contrary to the plain one (p. 11).
Key Takeaways and Practical Implications
This split decision offers several powerful lessons for patent practitioners, IP owners, and inventors.
The Specification Is Paramount in Equivalents Analysis: The holding on the ‘491 patent is a clear warning: the doctrine of equivalents cannot rescue an infringement claim when the accused product cannot perform the explicit functional benefits touted in the patent’s specification. When drafting a utility patent, every “virtue” and “advantage” described in the specification helps define the invention, but it can also create a clearer, sharper boundary that an accused infringer might design around. Conversely, for litigators, this opinion provides a powerful defensive tool: if an accused product is functionally inferior in the specific ways the patent highlights as inventive, an argument for non-equivalence is substantially strengthened.
Choose Descriptive Words Carefully in Design Patents: The D’930 patent remand highlights the risk of descriptive statements in design patent applications. While intended to clarify, the single word “transparency” became the pivot point for the entire infringement analysis. The applicant’s choice to use “transparency” instead of “translucency” (the property of the accused product) had profound consequences. This reinforces the need for extreme precision. Any descriptive text in a design patent should be scrutinized for ambiguity and unintended limitations.
Cautious Drafting: Practitioners describing an invention, whether in a utility or design patent, must be cautious. For instance, describing a process as “transparent” could be litigated for years if the term’s plain meaning differs from its technical implementation. Using broad, functional language without tethering it to specific, limiting examples remains a difficult but necessary balancing act.
Conclusion
The Smartrend v. Opti-Luxx decision provides a valuable analysis of two seemingly common but complex patent disputes. It reinforces the authority of the patent specification in defining the functions of an invention, thereby cabining the reach of the doctrine of equivalents. It also reaffirms that in design patents, as in all patent law, words have specific meanings. The court’s insistence on the plain meaning of “transparency” over a muddled interpretation that included “translucency” underscores a commitment to precision and predictability in patent interpretation, a principle that benefits the entire innovation ecosystem.
This opinion presents a fascinating juxtaposition: a rigorous analysis of function (for the utility patent) side-by-side with a precise analysis of ornament (for the design patent). Yet, in both instances, the patentee’s own words proved decisive. For the utility patent, the descriptive words in the specification—”removably receive” (p. 16), “extols the virtues” (p. 16)—were used to define the boundaries of the function at issue in the equivalents test. For the design patent, the single descriptive word “transparency” (p. 10) defined the ornamental appearance, overriding a potentially broader interpretation of the drawings.
This leads to a critical question: is it a good bet to rely on words in a design patent? The default claim is “as shown.” By adding “and described” (p. 9), a patentee takes a gamble. Here, the word “transparency” acted as a fatal limitation, handing the alleged infringer a clear, objective non-infringement argument. The cautious practitioner should be wary, as relying on drawings alone often provides more flexibility.
Case Citation: Smartrend Manufacturing Group (SMG), Inc. v. Opti-Luxx Inc., Nos. 2024-1616, 2024-1650 (Fed. Cir. Nov. 13, 2025).
